Gearbox Housing

Ruggedised die-cast Aluminium

Worm Gear Material

Brone,steel or glass-filled plastic

Lubrication

Grease lubricated & sealedfor life

Gearbox Output Bearing Type

High quality ball bearing

Insulation Class

F(contact us for classB)

Brush Type

Integral or removable

Ambient Operating Temperature

-20℃ to +40℃

Part Number

Voltage

Ratlo

No load Speed

Torque

Rated Current

Rated Speed

Rated Power

Length

Units

V

/

RPM

Nm

A

RPM

W

mm

ZJD8025A

12

60:1

50

37

50

40

600

240.5

ZJD8025B

12

90:1

60

50

75

48

900.0

270.5
